Work Site Illumination: Heavy Duty, Redefined.

Quality Engineering and Durable Components Make HOLT CAT the Preferred Supplier for Safe Work Site Illumination.

From construction sites and sporting events to mining and oil field applications, HOLT CAT® offers heavy-duty light towers to meet your work site lighting needs. With superior design, our tough galvanized mast and outriggers are designed to withstand the stress and strain of frequent usage. In addition, an industry-proven, durable Cat® engine assures you are running the highest quality light towers available.

There are two HOLT work site illumination models to choose from:

8 Kw Widebody Trailer Mounted Four 1,000-watt Lights 360-degree Rotation 29' Mast 70-gallon Diesel Tank Oil and Coolant Shutdowns One 120v 15 amp GFCI Duplex Receptacle Overall Length: 15'6' Overall Width (towing): 6'10'' Height (stored position): 8'4'' Maximum Width: 9'5'' 15'' Tires and Wheels Cat C1.1 Liter Diesel Engine May be towed in tandem

20 kW Widebody Trailer Mounted Four 1,000-watt Lights 360-degree Rotation 29' Mast 70-gallon Diesel Tank Oil and Coolant Shutdowns One 120v 15 amp GFCI Duplex Receptacle One 120v 30 amp GFCI Duplex Receptacle One 240v 30 amp Twist Lock One RV 30 amp Receptacle One RV 50-amp Receptacle Overall Length: 15'6'' Overall Width (towing): 6'10'' Height (stored position): 8'4'' Maximum Width: 9'5'' 15'' Tires and Wheels Cat C2.2 Liter Diesel Engine May be towed in tandem

Fast and Easy Set Up

HOLT CAT 20kW light towers feature a self-braking dual winch system for fast, easy tower erection. The 8kW single winch system incorporates an ergonomically positioned handle for easy raising and lowering.

Easy Service and Low Cost of Operation

Quick connect light fixtures, control boxes and ballast boxes allow for easy service with less downtime. Major common components across HOLT CAT models minimize the number of parts needed for service.

The HOLT CAT 8kW and 20kW wide body light towers are durable, cost-effective solutions for all work site illumination requirements. The full-sized, 29' extended height floodlight towers provide 4,000 watts of light. HOLT heavy-duty light towers provide illumination for up to 7.5 acres, 360 degrees of tower rotation for accurate light positioning and 70 gallons of fuel capacity for long run time. Additionally, these units may be towed in tandem, saving on transportation costs.  HOLT’s towers are designed to help get the job completed on time and on budget by offering the right combination of capabilities and value.

A HOLT CAT® sales representative will assist you in developing your work site lighting requirements. Our professional staff is available 24/7.
